A NUMERICAL PROCEDURE FOR CALCULATION OF STRESS

INTENSITY FACTORS AND ITS USE FOR LIFE ASSESSMENT OF

STEAM TURBINE HOUSING OF THERMAL POWER PLANT

G. Jovičić, M. Živković, M. Kojić, S. Vulović

Faculty of Mechanical Engineering, Kragujevac, Serbia and Montenegro

INTRODUCTION

Studies of fracture mechanics emerged in the early twentieth century. Among a num-

ber of researchers, Griffith’s idea of “minimum potential energy” provided a foundation

for all later successful theoretical studies of fracture, especially for brittle materials. But it

was not until after World War II that fracture mechanics developed as a discipline.

Derived from Griffith’s theorem, the concept of energy release rate,

G

, was first intro-

duced by Irwin, in a form more useful for engineering applications. Irwin defined an

energy release rate or the crack extension force tendency which can be determined from

stress and displacement fields in the vicinity of the crack tip rather then from an energy

balance for elastic solid as a whole, as Griffith suggested.

Conservation integrals in elasticity have been widely applied to fracture mechanics,

among which the

J

integral is the most popular one. The

J

integral is path independent for

elastic solids, and can be shown that the integral is identical to Irwin’s energy release rate

associated with the collinear extension of a crack in elastic solid [1].

1. DETERMINATION OF FRACTURE PARAMETERS IN THE PAK PROGRAM

1.1. Equivalent domain integral method (EDI)

Rice [1] defined a path-independent

J

-integral for two-dimensional crack problems in

linear and nonlinear elastic materials. As shown in Fig. 1,

J

is the line integral surround-

ing a two-dimensional crack tip and is defined as

1

1

,1

0

lim (

)

S

S

j

ij i

j

J

W u n

δ

σ

Γ → Γ

=

−

∫

d

Γ

,

i

,

j

= 1,2

(1)

where

W

is the strain energy density given by

1

1

2

2

ij ij

ijkl kl ij

W

C

σ ε

ε ε

=

=

(2)

and

n

j

is the outward normal vector to the integration contour

Γ

g

around the crack tip

(Fig. 1),

σ

ij

is the stress tensor,

ε

ij

is the strain tensor,

C

ijkl

is the constitutive tensor and

u

i

are components of the displacement vector.

Knowles and Stenberg [2] noted that this can be considered as the first component of a

vector

,

0

lim (

)

S

S

k

kj

ij i k j

J

W u n

δ

σ

Γ → Γ

=

−

∫

d

Γ

,

i

,

j

,

k

= 1,2

(3)

which is also path independent.

321
